Display system settings
366
1SVC 440 795 M1100
Example:
MB 01 to MB 04, C 12 to C 16, DB 01 to DB 16, T 26 to T 32
should be retentive.
124 bytes have been assigned to the retentive data range.
76 bytes are still available.
Deleting ranges
Set the ranges to be erased to the values from 00 to 00.
E.g.:
MB 00 -> MB 00. The markers are no longer
retentive.
Deleting retentive actual values of markers and
function blocks
The retentive actual values are cleared if the following is
fulfilled (applies only in STOP mode):
• When the circuit diagram is transferred from CL-SOFT (PC)
or from the memory module to the display system, the
retentive actual values are reset to 0. This also applies
when there is no program on the memory module, in
which case the old circuit diagram is retained in the
display system.
• When changing the respective retentive range.
• When the circuit diagram is deleted via the DELETE FUNCT
menu.
Transferring retentive behaviour
The retentive setting is a circuit diagram setting. In other
words, the retention setting is on the memory module and is
transferred with the circuit diagram when uploading or
downloading from the PC.
MB 01 -> MB 04
C 12 -> C 16
CH 00 -> CH 00
CI 00 -> CI 00
DB 01 -> DB 16
T 26 -> T 32
B:076
