Technical data
407
1SVC 440 795 M1100
Other inductive loads:
Analog output
T
0.95
= 15 ms
R = 48 O
L = 0.24 H
Utilisation factor g = 0,25
Relative duty factor % 100
Max. switching frequency
f = 0.5 Hz
Max. duty factor
DF = 50 %
Switching operations/h 1500
Inductive loading with external suppressor circuit for each load
(a section “Connecting transistor outputs”, page 64)
Utilisation factor g = 1
Relative duty factor % 100
Max. switching frequency
Max. duty factor
Switching operations/h Depending on the
suppressor circuit
CL-LDR.17DC2,
CL-LDT.17DC2
Number 1
Electrical isolation
To power supply No
To the digital inputs No
To the digital outputs Yes
To the CL-NET network Yes
Output type DC voltage
Signal range V DC 0 to 10
Output current max. mA 10
Load resistor k O 1
Short-circuit and overload proof Yes
