267
1SVC 440 795 M1100
5 Visualization with the
display system
In the following description, the term “visualization” is used
for the display and operator function.
Whilst it is possible to enter the circuit diagram using
CL-SOFT or via the device keypad, all visualization functions
can only be programmed with CL-SOFT. Only from this
software can the visualization functions be loaded onto the
display system module (download function).
This chapter describes the basic operating steps required for
using the visualization functions via CL-SOFT by means of
examples. The CL-SOFT help offers a detailed description of
the software.
Screens CL-SOFT manages the visualization elements in screens.
Visualization elements that you can position in the screens
are called screen elements in the following descriptions. You
can use up to 255 screen elements in a screen. Due to the
memory layout it is advisable to use several screens
(a section “Memory layout”, page 268).
The following screen elements are available:
• Static text,
• Bit display,
•Date and time,
•Bitmap,
• Numerical value,
• Value entry,
• Message text.
The examples illustrate the use of the individual screen
elements.
