CL-NET network topologies,
addressing and functions
323
1SVC 440 795 M1100
Example 1:
Station 1 is to read the input I1 of station 2 and write to
output Q1 of station 2. Station 2 does not have a circuit
diagram.
Figure: 180: Circuit diagram in station 1
Example 2:
Marker M 01 of station 4 is to switch the output Q1 of
station 3 via the network. Both stations have a circuit
diagram.
Figure: 181: Circuit diagram in station 4: Set coil 01 in station 3
Figure: 182: Circuit diagram in station 3: Get value from coil 01
in station 4
h
Every station with a circuit diagram has read access to the
physical station inputs and outputs of other stations and
can process them locally.
2I 01-----------------------------Ä2Q 01
M 01-----------------------------Ä3SN 01
4RN 01-----------------------------Ä Q 01
