ABB FSPS-21 User Manual

NotesDescriptionValue
(hex)
F-Parameter checksum length different from
3 octets. This device supports only three (3)
octet CRC2.
Parameter "F_CRC_Length" does not match
the generated values.
69
(0x0045)
Version of F-Parameter defined for this device
at F-Host is not correct. This device supports
only V2.
Parameter "F_Par_Version" set incorrectly.70
(0x0046)
Checksum CRC1 calculated over the F-Para-
meters does not match the checksum value
in the F-Parameters.
CRC1 Fault71
(0x0047)
Unsupported PROFINET submodule identific-
ation number received from the controller sta-
tion upon PROFINET connection, or general
error in the F-Parameters.
Device-specific diagnosis information72
(0x0048)
Not in use for FSPS-21-73...75
Reserved F_Block_ID bit combination used in
F_Prm_Flag2 in F-Parameters.
F_Block_ID not supported76
0x004C
CRC2 checksum is calculated over F-Paramet-
ers, sequence number and transmitted/re-
ceived data. If CRC2 is wrong, then transmit-
ted/received data might be corrupted or from
wrong device.
Transmission error: data inconsistent (CRC2
error)
77
0x004D
PROFIsafe device did not receive new data
within the configured watchdog period. A pos-
sible solution is to increase watchdog time (if
safety calculation allows) or decrease
PROFINET cycle time.
Transmission error: timeout (F_WD_Time or
F_WD_Time_2 elapsed)
78
0x004E
￭ Typical communication errors
This table lists some typical error situations in the PROFINET and PROFIsafe communication.
What to doCauseFault
Check the station name in drive
parameter 51.25 PN Name Index
and in the PLC configuration.
The FSPS-21 station name saved
in the drive parameter settings does
not match the station name of the
FSPS-21 in the PLC configuration.
You cannot start the PROFINET
communication.
Check the IP address in drive para-
meter settings and in the PLC con-
figuration.
The FSPS-21 IP address saved in
the drive parameter settings does
not match the IP address of the
FSPS-21 in the PLC configuration.
Check drive parameter 51.01 or
54.01.
The FSPS-21 is not configured for
the PROFINET communication.
Check the value of parameter 51.24
F-destination address.
The PROFIsafe destination address
of the FSPS-21 in the drive paramet-
er settings does not match the
PROFIsafe destination address of
the FSPS-21 in the PLC configura-
tion.
You cannot start the PROFIsafe
communication.
PROFIsafe 171
