DefaultDescriptionName/ValueNo.
0
See parameter 02 FBA data out 1.
FBA data out 3 …
FBA data out12
03 ...
10
1)
11 (CW 32bit) is the default setting if the Transparent32 profile is used.
FSPS-21 configuration parameters – group C (group 3)
Note:
The actual parameter group number depends on the drive type. Group C (group 3)
corresponds to:
• parameter group 52 in ACS380 and ACS580
• parameter group 52 in ACS880 if the adapter is installed as fieldbus adapter A or group
55 if the adapter is installed as fieldbus adapter B.
DefaultDescriptionName/ValueNo.
4 or 14
1)
Selects the resolution of status word (16 bit or 32 bit)
sent by the drive.
FBA data in 1 (drive
to master)
01
Status word (16 bits)4 = SW 16bit
Status word (32 bits)14 = SW 32bit
0 or 5Selects data word 1 sent by the drive over the
PROFINET network. The content is defined by a
decimal number in the range of 0 to 9999 as follows:
FBA data in 2 (drive
to master)
02
Not used0
Virtual address area of drive control1...99
Parameter area of the drive101...
9999
Not used0 = None
Status word (16 bits)4 = SW 16bit
Actual value ACT1 (16 bits)5 = Act1 16bit
Actual value ACT2 (16 bits)6 = Act2 16bit
Status word (32 bits)14 = SW 32bit
Actual value ACT1 (32 bits)15 = Act1 32bit
Actual value ACT2 (32 bits)16 = Act2 32bit
Status word 2 (16 bits)24 = SW2 16bit
Parameter index with format xxyy, where101…9999
• xx is the parameter group number (1…99)
• yy is the parameter number index within that group
(01…99).
Path to parameter area selection.Other
PROFINET IO – Start-up 55
