Status word contents
The table below shows the contents of the Status word for the ABB Drives communication
profile. The upper case boldface text refers to the states shown on page 83.
STATE/DescriptionValueNameBit
READY TO SWITCH ON1RDY_ON0
NOT READY TO SWITCH ON0
READY TO OPERATE1RDY_RUN1
OFF1 ACTIVE0
OPERATION ENABLED1RDY_REF2
OPERATION INHIBITED0
FAULT1TRIPPED3
No fault0
OFF2 inactive1OFF_2_STA4
OFF2 ACTIVE0
OFF3 inactive1OFF_3_STA5
OFF3 ACTIVE0
SWITCH-ON INHIBITED1SWC_ON_ INHIB6
–0
Warning/Alarm1ALARM7
No warning/alarm0
OPERATION. Actual value equals reference (= is within tolerance
limits, i.e., in speed control, speed error is 10% max. of nominal
motor speed).
1AT_SETPOINT8
Actual value differs from reference (= is outside tolerance limits).0
Drive control location: REMOTE (EXT1 or EXT2)1REMOTE9
Drive control location: LOCAL0
Actual frequency or speed equals or exceeds supervision limit
(set by drive parameter). Valid in both directions of rotation.
1ABOVE_ LIMIT10
Actual frequency or speed within supervision limit0
External Control Location EXT2 selected. Note concerning
ACS880: This bit is effective only if the fieldbus interface is set
as the target for this signal by drive parameters. User bit 0 selec-
tion (06.33)
1EXT_CTRL_ LOC11
External Control Location EXT1 selected0
External Run Enable signal received.1EXT_RUN_ ENABLE12
Note concerning ACS880: This bit is effective only if the fieldbus
interface is set as the target for this signal by drive parameters.
User bit 1 selection (06.34)
No External Run Enable signal received0
