STATE/DescriptionValueNameBit
Continue operation (OFF3 inactive).1OFF3_ CONTROL2
Emergency stop, stop within time defined by drive parameter.
Proceed to OFF3 ACTIVE; proceed to SWITCH-ON INHIBITED.
0
Warning: Ensure that motor and driven machine can be stopped
using this stop mode.
Proceed to OPERATION ENABLED.1INHIBIT_ OPERATION3
Note:
Run enable signal must be active; see drive documentation. If the
drive is set to receive the Run enable signal from the fieldbus, this
bit activates the signal.
Inhibit operation. Proceed to OPERATION INHIBITED.0
Normal operation. Proceed to RAMP FUNCTION GENERATOR:
OUTPUT ENABLED.
1RAMP_OUT_ ZERO4
Force Ramp Function Generator output to zero. Drive ramps to
stop (current and DC voltage limits in force).
0
Enable ramp function.1RAMP_HOLD5
Proceed to RAMP FUNCTION GENERATOR: ACCELERATOR
ENABLED.
Halt ramping (Ramp Function Generator output held).0
Normal operation. Proceed to OPERATION.1RAMP_IN_ ZERO6
Note:
This bit is effective only if the fieldbus interface is set as the source
for this signal by drive parameters.
Force Ramp Function Generator input to zero.0
Fault reset if an active fault exists. Proceed to SWITCH-ON INHIB-
ITED.
0 → 1RESET7
Note:
This bit is effective only if the fieldbus interface is set as the source
for this signal by drive parameters.
Continue normal operation.0
Reserved8 … 9
Fieldbus control enabled1REMOTE_ CMD10
Control word and reference not getting through to the drive, except
for CW bits OFF1, OFF2 and OFF3.
0
Select External Control Location EXT2. Effective if control location
parameterized to be selected from fieldbus.
1EXT_CTRL_ LOC11
Select External Control Location EXT1. Effective if control location
parameterized to be selected from fieldbus.
0
Drive-specific (For information, see the drive documentation.)12 ...
15
PROFINET IO – Communication profiles 81
