DefaultDescriptionName/ValueNo.
N/ARead-only. Displays the parameter table revision of
the fieldbus adapter module mapping file stored in the
memory of the drive. In format xyz, where
x = major revision number
y = minor revision number
z = correction number
OR
in format axyz, where
a = major revision number
xy = minor revision numbers
z = correction number or letter.
FBA A/B par table ver28
Parameter table revision
N/ARead-only. Displays the drive type code of the fieldbus
adapter module mapping file stored in the memory of
the drive.
FBA A/B drive type
code
29
Drive type code of the fieldbus adapter module map-
ping file
N/ARead-only. Displays the fieldbus adapter module
mapping file revision stored in the memory of the drive
in decimal format.
FBA A/B mapping file
ver
30
Mapping file revision
0 = Idle
or
4 = Offline
Read-only. Displays the status of the fieldbus adapter
module communication.
Note: The value names may vary by drive.
D2FBA A/B comm
status
31
Note: Only active drive-controlled channel will change
comm status online. PROFIsafe alone will not change
the comm status.
Adapter is not configured0 = Idle
Adapter is initializing.1 = Exec.init
A timeout has occurred in the communication between
the adapter and the drive.
2 = Time out
There is an internal error in the communication
between the adapter and the drive. Contact your local
ABB representative.
3 = Conf.err
Adapter is off-line4 = Off-line
Adapter is on-line5 = On-line
Adapter is performing a hardware reset.6 = Reset
N/ARead-only. Displays patch and build numbers of the
adapter module's firmware version in xxyy format,
where:
FBA A/B comm SW
ver
32
xx = patch number
yy = build number.
Example: If the firmware version (<ma-
jor>.<minor>.<patch>.<build>) is 3.10.200.13, the value
C80D is displayed. If the version is 3.10.0.0, the value
0 is displayed.
See also parameter 33.
PROFINET IO – Start-up 53
