• Always tighten the joint by hand, and never use pneumatic tools.
• Use the correct tightening technique, that is do not jerk. Tighten the screw
in a slow, flowing motion.
• Maximum allowed total deviation from the specified value is 10%!
Oil-lubricated screws with slotted or cross-recess head screws
The following table specifies the recommended standard tightening torque for
oil-lubricated screws with slotted or cross-recess head screws.
Note
A special torque specified in the repair, maintenance or installation procedure
overrides the standard torque.
Oil-lubricated screws with allen head screws
The following table specifies the recommended standard tightening torque for
oil-lubricated screws with allen head screws.
Note
A special torque specified in the repair, maintenance or installation procedure
overrides the standard torque.
Tightening torque (Nm)
Class 12.9, oil-lubric-
ated
Tightening torque (Nm)
Class 10.9, oil-lubric-
ated
Tightening torque (Nm)
Class 8.8, oil-lubricated
Dimension
--6M5
--10M6
403424M8
806747M10
14011582M12
340290200M16
670560400M20
1150960680M24
Lubricated screws (Molycote, Gleitmo or equivalent) with allen head screws
The following table specifies the recommended standard tightening torque for
screws lubricated with Molycote 1000, Gleitmo 603 or equivalent with allen head
screws.
Note
A special torque specified in the repair, maintenance or installation procedure
overrides the standard torque.
Tightening torque (Nm)
Class 12.9, lubricated
i
Tightening torque (Nm)
Class 10.9, lubricated
i
Dimension
3528M8
Continues on next page
226 Product manual - IRB 2400
3HAC022031-001 Revision: P
© Copyright 2004-2018 ABB. All rights reserved.
7 Reference information
7.4 Screw joints
Continued
