NoteAction
Where to find type of oil and total
amount is detailed in Type and
amount of oil in gearboxes on
page 144.
Adjust the oil level, if required.8
Further information about how to fill
the oil may be found in the section
Filling, oil, axis 6 on page 160.
Tightening torque: 24 Nm.Refit the oil plug.9
WARNING
Do not mix oil types! If wrong oil is refilled, the
gearbox must be rinsed as detailed in Technical
reference manual - Lubrication in gearboxes.
10
Product manual - IRB 6660 125
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
3 Maintenance
3.3.5 Inspecting the oil level in axis-6 gearbox
Continued
