7.7 Special tools
General
All service instructions contain lists of tools required to perform the specified
activity. The required tools are a sum of standard tools, defined in the section
Standard tools on page 381, and of special tools, listed directly in the instructions
and also gathered in this section.
Calibration equipment, Calibration Pendulum
The following table specifies the calibration equipment needed when calibrating
the robot with the Calibration Pendulum method.
The robot is calibrated by either Calibration Pendulum or Axis Calibration at factory.
Always use the same calibration method as used at the factory.
Information about valid calibration method is found on the calibration label or in
the calibration menu on the FlexPendant.
If no data is found related to standard calibration, Calibration Pendulum is used
as default.
NoteArt. no.Description
Complete kit that also includes operating
manual.
3HAC15716-1Calibration Pendulum toolkit
Calibration equipment, Axis Calibration
The following table specifies the calibration equipment needed when calibrating
the robot with the Axis Calibration method.
The robot is calibrated by either Calibration Pendulum or Axis Calibration at factory.
Always use the same calibration method as used at the factory.
Information about valid calibration method is found on the calibration label or in
the calibration menu on the FlexPendant.
If no data is found related to standard calibration, Calibration Pendulum is used
as default.
NoteArt. no.Description
Delivered as a set of calibration tools.3HAC055412-
001
Calibration tool box, Axis Cal-
ibration
Required if Axis Calibration is the valid
calibration method for the robot.
Continues on next page
382 Product manual - IRB 6660
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
7 Reference information
7.7 Special tools
