Oil exchange equipment
The following table specifies the recommended equipment for oil exchange.
NoteArt. no.Description
Includes:
• Vacuum pump with regulator,
hose and coupling
• Couplings and adapters
• Pump (manual) with hose and
coupling
• Graduated measuring glass
• Oil gun
• User instructions.
3HAC021745-001
Oil exchange equipment
Basic tools
The following table specifies the tools in the basic toolkit that are used for the
current robot model. This toolkit is necessary primarily when removing and refitting
the motors.
The tools are also listed directly in the instructions.
Art. no.QtyDescription
3HAC12342-11Extension 300mm for bits 1/2"
3HAC15520-12Guide pins M8 x 100
3HAC15520-22Guide pins M8 x 150
3HAC15521-12Guide pins M10 x 100
3HAC15521-22Guide pins M10 x 150
3HAC14459-11Lifting tool, motor ax 1
3HAC15534-11Lifting tool, motor ax 2, 3
3HAC14972-12Removal tool, motor M10x
Fits motors, axes 6.
Fits motors axes 1, 2 and 3.Removal tool, motor M12x
3HAC17105-11Rotation tool
-1Standard toolkit (content described in sec-
tion Standard tools on page 381)
Lifting tools
The following table specifies the lifting tools required during several of the service
procedures. The tools may be ordered separately and are also specified directly
in concerned instructions.
Article no.QtyDescription
1Hoisting block
1Lifting chain (used together with the hoisting
block)
3HAC15535-11Support, base and gearbox axis 1
3HAC15556-11Lifting tool, gearbox axis 1
Continues on next page
Product manual - IRB 6660 383
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
7 Reference information
7.7 Special tools
Continued
