Article no.QtyDescription
3HAC025333-005Lifting eye (used together with lifting tool
3HAC15556-1)
3HAC14586-11Lifting tool, motor
3HAC023240-0011Lifting tool, gearbox axes 2-3
3HAC023308-0011Lifting tool, frame
3HAC15607-11Lifting tool. complete robot
(User instruction 3HAC15971-1)
3HAC023098-0011Lifting tool, parallel arm
3HAC13605-11Lifting tool, wrist unit
3HAC14868-11Lifting tool, base
-1Standard toolkit (content described in sec-
tion Standard tools on page 381)
Special tools
The following table specifies the special tools required during several of the service
procedures. The tools may be ordered separately and are also specified directly
in concerned instructions.
Article no.QtyDescription
StandardKM8 socket
StandardKM10 socket
3HAC023132-001Pinion crank
3HAC023092-001Pressing, lower arm/balancing weight
3HAC023084-001Pressing, upper arm
3HAC5021-1Pressing, tie rod
3HAC5275-1Auxiliary shaft, long
3HAC5276-1Auxiliary shaft, short
3HAC5281-1Support shaft/bearing race
3HAC5222-1Tool for lubrication
3HAC023916-001Adapter for shaft axis 3
3HAC14446-1Guide sleeves
384 Product manual - IRB 6660
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
7 Reference information
7.7 Special tools
Continued
