1 Safety
1.2.3.7. Work inside the manipulator's working range
353HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
1.2.3.7. Work inside the manipulator's working range
WARNING!
If work must be carried out within the manipulator’s work area, the following points must be
observed:
• The operating mode selector on the controller must be in the manual mode position to
render the enabling device operational and to block operation from a computer link or
remote control panel.
• The manipulator’s speed is limited to max. 250 mm/s when the operating mode
selector is in the position Manual mode with reduced speed. This should be the normal
position when entering the working space. The position Manual mode with full speed
(100%) may only be used by trained personnel who are aware of the risks that this
entails. Manual mode with full speed (100%) is not available in USA or Canada.
• Pay attention to the rotating axes of the manipulator. Keep away from axes to not get
entangled with hair or clothing. Also, be aware of any danger that may be caused by
rotating tools or other devices mounted on the manipulator or inside the cell.
• Test the motor brake on each axis, according to the section Brake testing on page 32.
WARNING!
NEVER, under any circumstances, stay beneath any of the manipulator’s axes! There is
always a risk that the manipulator will move unexpectedly when manipulator axes are moved
using the enabling device or during other work inside the manipulator’s working range.
