8.3.9. Axis 3-4 Foundry, 3HAC13063-5 (IRB 7600 - 500/2.3)
3HAC022033-001 Revision: K448
© Copyright 2004-2011 ABB. All rights reserved.
8.3.9. Axis 3-4 Foundry, 3HAC13063-5 (IRB 7600 - 500/2.3)
Part list
Tube shaft 2,55 Foundry, 3HAC15932-2
Item Qty Art. no. Description Note
102.1 1 3HAC022181-001 Material set ax 4 See table Material set axis
4, 3HAC022181-001 on
page 443.
102.2 1 3HAC15932-2 Tube shaft 2,55 See table below.
102.3 1 3HAC13062-1 Axis 3 See table Axis 3,
3HAC13062-1 on page
445.
Item Qty Art. number Description Note
102.2.1 1 3HAC10509-6 Tube shaft 2,55, cast
102.2.2 1 3HAC1383-2 Protection Cover compl.
