7.6. Standard toolkit
General
All service (repairs, maintenance, and installation) procedures contains lists of tools required
to perform the specified activity.
All special tools required are listed directly in the procedures while all the tools that are
considered standard are gathered in the standard toolkit and defined in the following table.
This way, the tools required are the sum of the standard toolkit and any tools listed in the
instruction.
Contents, standard toolkit
Qty Tool Rem.
1 Ring-open-end spanner 8-19 mm
1 Socket head cap 5-17 mm
1 Torx socket no: 20-60
1 Box spanner set
1 Torque wrench 10-100 Nm
1 Torque wrench 75-400 Nm
1 Ratchet head for torque wrench 1/2
2 Hexagon-headed screw M10x100
1 Bit for: Socket head cap no. 14 socket 40 mm L100 mm
1 Bit for: Socket head cap no. 14 socket 40 mm L 20 mm To be shortened to 12 mm
1 Bit for: Socket head cap no. 6 socket 40 mm L 145 mm
1 Bit for: Socket head cap no. 6 socket 40mm bit L220 mm
