ABB M2004 User Manual

10 Circuit Diagram
10.1. About circuit diagrams
4693HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
10 Circuit Diagram
10.1. About circuit diagrams
Overview
The circuit diagrams are not included in this manual, but delivered as separate documents on
the documentation DVD. See following for correct article numbers.
Controllers
Robots
Product Article numbers for circuit diagrams
IRC5 3HAC024480-005
IRC 5 Compact 3HAC031403-003
IRC5 Panel Mounted Controller 3HAC026871-006
Euromap 3HAC024120-004
Product Article numbers for circuit diagrams
IRB 120 3HAC031408-003
IRB 140 type C 3HAC6816-3
IRB 260 3HAC025611-001
IRB 360 3HAC028647-009
IRB 460 3HAC036446-005
IRB 660 3HAC025691-001
IRB 760 3HAC025691-001
IRB 1410 3HAC2800-3
IRB 1600 type A 3HAC021351-003
IRB 2400 3HAC6670-3
IRB 2600 3HAC029570-007
IRB 4400/4450S 3HAC9821-1
IRB 4600 3HAC029038-003
IRB 4600 Foundry Prime 3HAC029038-003
IRB 6400RF 3HAC8935-1
IRB 6600 type A 3HAC13347-1
3HAC025744-001
IRB 6600 type B 3HAC13347-1
3HAC025744-001
IRB 6620 3HAC025090-001
IRB 6620LX 3HAC025090-001
IRB 6640 3HAC025744-001
IRB 6650S 3HAC13347-1
3HAC025744-001
IRB 6660 3HAC029940-001
3HAC025744-001
Continues on next page
