ABB M2004 User Manual

8 Spare part / part list
8.3.12. Material set axis 1-2, 3HAC13077-1
3HAC022033-001 Revision: K456
© Copyright 2004-2011 ABB. All rights reserved.
8.3.12. Material set axis 1-2, 3HAC13077-1
Part list
Item Qty Art. number Description Note / Dimension
109.301 1 3HAC12641-1 RV 700F incl. gear See table RV 700F incl.
gear, 3HAC12641-1 on
page 457.
109.302 1 3HAC11198-1 Cover, machining
109.303 1 3HAC14698-1 Friction washer 381x438x1
109.304 20 3HAB3409-92 Hex socket head cap
screw
M16x110
109.305 20 3HAA1001-186 Washer 17x25x3
109.306 1 3HAC14723-1 Rot ac motor incl pinion See table Rot ac motor
incl pinion,
3HAC14723-1 on page
458.
109.307 1 3HAC025752-001 Rot. AC motor incl.
pinion
IRB 7600 - 500/2.55
See table Rot. AC
motor incl. pinion,
3HAC025752-001 on
page 458.
109.307 1 3HAC14724-1 Rot ac motor incl pinion IRB 7600 -500/2.3, -
400/2.55, -340/2.8, -
325/3.1, -150/3.5
See table Rot ac motor
incl pinion,
3HAC14724-1 on page
458.
109.308 8 3HAB3409-50 Hex socket head cap
screw
M10x40
109.309 8 3HAB4233-1 Washer
109.310 1 3HAC12252-1 Bottom plate
109.311 1 3HAC14131-1 Connection plate, base
109.312 1 3HAC11774-3 Adapter, complete
109.313 1 3HAC11769-1 Cable guide, ax.1
109.320 1 3HAC021287-001 Sync plate
109.321 1 3HAC12671-6 Block for calibration
109.322 1 3HAC14024-1 Protection screw and o-
ring
109.324 24 9ADA618-56 Torx pan head screw M6x16
109.325 3 9ADA618-57 Torx pan head screw M6x20
109.326 1 3HAC022286-001 Serial measurement unit
DSQC 633
109.327 1 3HAC14788-3 Cover SMB and BRU See table Cover SMB
and BRU, 3HAC14788-
3 on page 458.
109.328 1 3HAC16831-1 Battery pack
109.329 1 3HAC13151-1 Cable battery/SMB
109.330 2 3HAC11526-1 Stud screw M6x150
Continues on next page
