ABB M2004 User Manual

8 Spare part / part list
8.3.12. Material set axis 1-2, 3HAC13077-1
4573HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
RV 700F incl. gear, 3HAC12641-1
109.331 1 3HAC13152-1 Bracket SMB
109.332 1 3HAC14791-3 Cover battery box See table Cover battery
box, 3HAC14791-3 on
page 458.
109.334 6 9ADA618-53 Torx pan head screw M6x8
109.335 1 3HAA2166-23 VK-Cover
109.336 1 3HAC020122-001 Attachment plate
109.337 2 3HAC12625-1 Strap, Velcro
109.338 1 3HAC14793-1 Bracket
109.339 1 3HAC15619-1 Cable, FB7-SMB 1.7
109.340 1 ml 12690014-413 Locking liquid
109.341 7,600 ml 3HAC032140-001 Lubricating oil:
Kyodo Yushi TMO 150
NOTE! Do not mix with
other oils!
109.342 4,800 ml 3HAC032140-001 Lubricating oil:
Kyodo Yushi TMO 150
109.344 1 ml 3HAB7116-1 Locking liquid
109.345 2 9ADA267-6 Hexagon nut M6
109.346 1 3HAC16036-1 BU w. buttons DSQC
561
3HAC14219-1 BU at the base Read more about the
difference in section
Replacement of brake
release unit on page
301.
3HAC12989-1 BU at the base
109.347 1 3HAC2744-1 Push button guard
109.348 4 9ADA629-56 Torx pan head roll. screw M6x16
109.349 2 9ADA618-58 Torx pan head screw M6x25
109.350 1 3HAC4813-1 Cover, push button
guard
109.351 10 9ADA618-44 Torx pan head screw M5x12
109.352 1 3HAC14024-1 Protection screw and o-
ring
109.353 1 3HAC17423-1 Washer
109.354 1 9ADA269-4 Hexagon nut M8
109.360 4 3HAB3558-14 Lock washer
Item Qty Art. number Description Note / Dimension
Item Qty Art. number Description Note
109.301.1 1 3HAC17272-1 RV 700F-269,21
assembly
See following table.
109.301.2 1 3HAC11636-1 Gear Z2 /2.3
Continued
Continues on next page
