8 Spare part / part list
8.3.12. Material set axis 1-2, 3HAC13077-1
3HAC022033-001 Revision: K458
© Copyright 2004-2011 ABB. All rights reserved.
RV 700F-269,21 assembly, 3HAC17272-1
Rot ac motor incl pinion, 3HAC14723-1
Rot. AC motor incl. pinion, 3HAC025752-001
Rot ac motor incl pinion, 3HAC14724-1
Cover SMB and BRU, 3HAC14788-3
Cover battery box, 3HAC14791-3
Item Qty Art. number Description Note
109.301.1.1 1 3HAC10122-21 RV 700F, i=269,21
109.301.1.2 1 3HAB3772-51 O-ring
Item Qty Art. number Description Note
109.306.1 1 3HAC17484-1 Rotational ac motor M1
109.306.2 1 3HAC11350-1 Pinion RV 500C & RV 320C
109.306.3 1 21522012-430 O-ring D=89.5x3
Item Qty Art. number Description Note
109.307.1 1 3HAC025724-001 Rotational AC motor, M13
109.307.2 1 3HAC11632-1 Pinion Z1 /2.3
109.307.3 1 21502012-430 O-ring D=89.5x3
Item Qty Art. number Description Note
109.307.1 1 3HAC17484-1 Rotational ac motor M1
109.307.2 1 3HAC11632-1 Pinion Z1 /2.3
109.307.3 1 21522012-430 O-ring D=89.5x3
Item Qty Art. number Description Note
109.327.1 1 3HAC023546-003 Cover SMB
109.327.2 1 3HAC14788-2 Gasket
109.327.3 1 3HAC023764-001 Rubber cloth
Item Qty Art. number Description Note
109.332.1 1 3HAC14791-1 Cover
109.332.2 1 3HAC14791-2 Gasket
109.332.3 1 3HAC16977-1 Warning label battery
