Table 4: Ethernet Configuration tabs
Tab Description
Access points This tab is used to configure access points.
The access point tab shows the access points
based on the supported hardware. For
example, if the 100FX-ST/100FX-LC hardware
modules are selected in hardware
configuration, the corresponding access points
will be available.
Merging unit
This tab is used to configure the merging unit.
Merging unit’s availability is based on the 9-2
order options and the hardware module
selection. For example, if OEM02 is selected,
the corresponding 9-12 merging units will be
available.
Routers
This tab is used to configure routers.
4. Save the configuration data in one of the alternative ways.
• Click the Save button on the toolbar.
• On the File menu, select Save.
• Press CTRL+S.
5.5 Using Graphical Display Editor
Graphical Display Editor is used for drawing the single-line diagram shown on the
graphical display of the IED. The diagram with its components corresponds to the
actual configuration.
1. In Plant Structure, select an IED.
2. On the Tools menu, click Graphical Display Editor.
The presentation is empty when no page exists for the IED. If standard
configurations are used, a default single-line diagram presentation is displayed.
3. In the Symbol Library box, select either IEC or ANSI.
The symbols in the display pages and in the symbol library are changed.
4. On the toolbar, activate the Snap to grid and Show grid functions.
5. Create the single-line diagram.
5.5.1 Creating single-line diagrams
1. Add primary equipment to the display page by dragging from the Symbol
Library.
• Rotate the symbols with the Rotate left and Rotate right buttons on the
toolbar.
• Select the size in the Symbol Size box.
2. Add junction symbols for connections.
3. Connect the symbols where necessary.
Section 5 1MRS757866 C
Use cases for engineering and commissioning
52 PCM600
Getting Started Guide
