Parameter Specification

Connection standard

• Type 1 cable

• Type 2 cable

• Type 2 socket

• Type 2 socket with shutter

According to IEC 62196-1, IEC 62196-2

Maximum output power (1 phase) 7.4 kW

Maximum output power (3 phase) 22 kW

11.14.2 AC output specifications (North America)

Parameter Specification

AC output voltage range 110 - 240V AC (1 phase)

Connection standard Type 1 cable according to SAE J1772

Maximum output voltage 19 kW

11.15 Specific power consumption specifications

Power consumption during normal opera-

tion

Specification [W]

Charging Mode 1 Phase 7

Charging Mode 3 Phase 10

11.16 Torque specifications

Parameter Specification [Nm][(lb.in.)]

Terminal block for the AC input 1.2 (10.6)

Terminal block for the communication wires

and the smart meter connections

0.5 (4.43)

Terminal block for the EV charge cable 1.2 (10.6)

Lower mounting screws 4.4 (38.9)

Technical data

BCM.V3Y01.0-EN | 001 57
