3-46 Machine Maintenance
Removing the Microphone 0
1. Perform the “Removing the LCD Panel” procedure described on page 3-43.
2. Release the microphone cable from the adhesive tapes securing them.
Figure 3-61. Microphone Adhesive Tapes
3. Gently pry the microphone off the LCD back panel.
Figure 3-62. Microphone

Acer Aspire V5-571 Specifications

General

Graphics	Intel HD Graphics 4000
Operating System	Windows 8
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	4GB DDR3
Storage	500GB HDD
Display	15.6-inch HD (1366 x 768)
Battery	4-cell Li-ion battery
Weight	2.3 kg
Ports	2 x USB 2.0, 1 x USB 3.0, HDMI, Ethernet
Wireless	802.11b/g/n
Webcam	HD webcam
