Agilent Technologies 8922M User Manual

4-81
Screens
Oscilloscope, Marker Controls
2. Controls This field selects the set of oscilloscope controls.
Choices Main
Trigger
Marker
3. Marker This field displays the signal level at the current marker position. The units-of-
measure for this field are determined by the AF Anl In selection.
See Also Screens: Audio, (AF Analyzer AF Anl In) Keys: ON/OFF,
HI LIMIT, LO LIMIT, REF SET, AVG, Units
4. Marker To
(Peak+)
This field causes the marker to move to the highest positive peak displayed.
5. Marker To (Peak−
)
This field causes the marker to move to the lowest negative peak displayed.
6. Meas Reset Selecting Meas Reset will erase any accumulated measurements used for calculating
a final result, and re-start the measurement process for the following functions:
• HI LIMIT
• LO LIMIT
• AVG
See Also Keys
7. Position This field controls the position of the marker.
