1-10 Overview
Compatible Modules
The 1747-ASB module supports all SLC 5/01 compatible I/O modules
(class 0 and 1). The following modules can be placed in the remote
chassis and remote expansion chassis:
• all discrete I/O modules
• all analog I/O modules
• BASIC Modules, Catalog Number 1746-BAS, -BAST
(SLC 5/01 mode)
• IMC 110 motion control module, Catalog Number 1746-HS
• Direct Communication Module, Catalog Number 1747-DCM
• Thermocouple/mV input modules, Catalog Number
1746-NT4, NT8
• RTD/Resistance Modules, Catalog Number 1746-NR4, NR8
• High Speed Counter Module, Catalog Number 1746-HSCE 2
1747-ASB Module Feature
The 1747-ASB module has the following features:
• communicates I/O data up to a maximum of 3040 meters
(10,000 feet)
• supports 57.6K, 115.2K, and 230.4K baud operation on the RIO
link
• supports any mix of 1746 discrete or analog I/O
• controls up to 30 slots using remote expansion chassis
• allows use of 2-slot, 1-slot, and 1/2-slot addressing
• allows for image sizes between 2 and 32 logical groups (user
selectable)
• incorporates enhanced operating status and troubleshooting
capability using three 7-segment displays
• provides non-volatile memory for convenient I/O module slot
keying
• provides discrete output module hold last state selection
• provides RIO link processor restart lockout selection
• incorporates extended node capability
• supports RIO block transfers and RIO discrete transfers for
analog and other specialty I/O modules
• supports complementary I/O on the RIO link
