98 Rockwell Automation Publication 1769-UM021G-EN-P - October 2015
Chapter 4 Complete Software Tasks Required at CompactLogix 5370 Controller Installation
Load the Controller Firmware
You must download the current firmware before you can use the
CompactLogix 5370 controller.
To load firmware, you can use any of the following:
• ControlFLASH™ software that installs with Logix Designer application
• AutoFlash that launches through the application when you download a
project and the controller does not have the matching firmware revision
• SD card (catalog numbers 1784-SD1 or 1784-SD2) with an image stored
on the card
If you use the ControlFLASH or AutoFlash utilities, you need an EtherNet/IP
network or USB connection to the controller.
The firmware is available with the application or you can download it from the
support website. Go to http://www.rockwellautomation.com/support.
Do not interrupt a firmware upgrade while it is in process. Firmware upgrade
interruption can cause the firmware revision of the CompactLogix 5370
controller to revert to its out-of-the-box revision level, that is, 1.xxx.
The controller firmware revision that is loaded via the ControlFLASH software
or the AutoFlash option can be overwritten after future controller power cycles
if the conditions described in Use the Secure Digital Card to Load Firmware
on
page 111 exist.
