Allen-Bradley DeviceNet 1203-GK5 User Manual

C-16 DeviceNet Objects (Class Code 0x10 — Parameter Group Object)
Class Code 0x10 — Parameter
Group Object
The Parameter Group Object identifies and provides access to groups
of parameters in a device grouping. The Parameter Group Object
provides convenient access to related sets of parameters.
Class Attributes
Instances
The number of instances varies based on the number of groups in the
SCANport product. One additional group is added for the module.
Instance Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Description
1 Get Parameter
group version
UINT Returns 1
2 Get Max Instance UINT Maximum instance number of
an object currently created in
this class level of the device.
8 Get Native
Language
USINT Language ID for all STRING
accesses.
0 = English
1 = French
2 = Spanish (Mexican)
3 = Italian
4 = German
5 = Japanese
6 = Portuguese
Instance Description
1 – (n - 1) SCANport product groups
n
➀
Module group
➀ n is the value returned by a get from class attribute 2 (max instance).
Attribute ID Access Rule Name Data Type Description
1 Get Group Name String SHORT_
STRING
A text string representing the group name (e.g., set-up,
frequency set).
Maximum number of characters = 16
2 Get Number of Members in
Group
UINT Number of parameters in group.
3 Get 1st Parameter Number
in Group
UINT Parameter instance number.
4 Get 2nd Parameter Number
in Group
UINT Parameter instance number.
n Get (n-2)th Parameter
Number in Group
UINT Parameter instance number.
