A-2 Specifications
1336-GM5 Board Specifications The following table gives the specifications for the 1336-GM5
DeviceNet communications board.
Category Specifications
Electrical Input Voltage
Input Current
(supplied via DeviceNet)
12 to 25 V DC
40 mA
Environmental Operating Temperature
Storage Temperature
Relative Humidity
0 to +50°C (32 to 122°F)
–40 to +85°C (–40 to 185°F)
0 to 95% non-condensing
Communications DeviceNet
Baud Rates
Distance Maximum
125, 250, 500 k BPS
500 m (1640 ft.) @ 125 k BPS
200 m (820 ft.) @ 250 k BPS
100 m (328 ft.) @ 500 k BPS
Mechanical Height
Width
Depth
71.1 mm (2.8 in.)
114.3 mm (4.5 in.)
12.7 mm (0.5 in.)
ESD
Susceptibility
Contact
Open Air
4 KV
8 KV
!
ATTENTION: The1336-GM5communicationsboard
contains ESD (Electrostatic Discharge) sensitive parts.
Static control precautions are required when installing,
testing, or servicing this assembly. Device malfunction
may occur if you do not follow ESD control procedures.
If you are not familiar with static control procedures,
refer to Rockwell Automation Publication 8000-4.5.2,
Guarding Against Electrostatic Damage, or other
applicable ESD protection handbook.
