DeviceNet Objects (Class Code 0x97 — SCANport Pass-Through Fault Object) C-21
Class Code 0x97 — SCANport
Pass-Through Fault Object
The SCANport Pass-Through Fault Object provides information on
the product’s fault queue.
Class Attributes
Instance Attributes
Attribute ID Access Rule Name Data Type Description
0 Set Write Fault Command BYTE 1 = Clear Faults
2 = Clear Fault Queue
3 = Reset Product
1 Get Read Number of Fault
Queue Entries
BYTE Reads the number of fault queue entries.
2 Get Read Fault Queue Trip
Index
BYTE Reads the index of the fault that tripped the product.
Attribute ID Access Rule Name Data Type Description
0 Get Read Fault Queue Entry
Full/All Info
STRUCT of
Fault Text ARRAY of BYTE 16 character string (no length information, no
terminating null).
Fault Code WORD Fault Code.
Fault Time Stamp STRUCT
BYTE 1/100 Second (0 – 99).
BYTE Second (0 – 59).
BYTE Minute (0 – 59).
BYTE Hour (0 – 23).
BYTE
Day of Week (0 – 6).
➀
BYTE Date (1 – 31).
BYTE Month (1 – 12).
BYTE
Year (0 – 99
➁
).
128 Get Fault Code and Time
Stamp
STRUCT of
Fault Code WORD Fault Code.
Fault Time Stamp STRUCT of
BYTE 1/100 Second (0 – 99).
BYTE Second (0 – 59).
BYTE Minute (0 – 59).
BYTE Hour (0 – 23).
BYTE
Day of Week (0 – 6).
➀
BYTE Date (1 – 31).
BYTE Month (1 – 12).
BYTE
Year (0 – 99
➁
).
129 Get Read Fault Text String
Only
ARRAY of BYTE 16 character string (no length information, no
terminating null).
➀
Sunday is a value of zero.
➁
Year is an offset from 1990.
