D-2 Supported PCCC Messages
Supported PCCC Messages The 1203-GK5 and 1336-GM5 support the following PCCC
messages:
Related Documentation For more information on PCCC messages, refer to the DF1 Protocol
and Command Set Reference Manual, publication 1770-6.5.16.
CMD FNC Message Definition Supported?
0x06 0x03 Identify Host and Some Status Yes
0x0F 0x67 PLC-5 Typed Write Yes
0x0F 0x68 PLC-5 Typed Read Yes
Logical ASCII Address Yes
Logical Binary Address No
PLC-2 System Address No
PLC-3 Symbolic Address No
0x0F 0xA1 SLC-500 Protected Typed Logical Read w/ 2 Address Fields — File, Element No
0x0F 0xA2 SLC-500 Protected Typed Logical Read w/ 3 Address Fields — File, Element,
Sub-Element
Ye s
0x0F 0xA9 SLC-500 Protected Typed Logical Write w/ 2 Address Fields — File, Element No
0x0F 0xAA SLC-500 Protected Typed Logical Write w/ 3 Address Fields — File, Element,
Sub-Element
Ye s
0x0F 0xAB SLC-500 Protected Typed Logical Write w/ 4 Address Fields — File, Element,
Sub-Element, Bit Mask
No
0x0F 0x95 Encapsulate Other Protocol message Yes
