DeviceNet Objects (Class Code 0x98 — SCANport Pass-Through Warning Object) C-23
Class Code 0x98 — SCANport
Pass-Through Warning Object
The SCANport Pass-Through Warning Object provides information
on the product’s warning queue.
Class Attributes
Instance Attributes
Attribute
ID
Access
Rule
Name Data Type Description
0 Set Write
Warning
Command
BYTE Write Warning Command.
1 = Clear Warnings
2 = Clear Warning Queue
3 = Reset Product
1 Set Read Number
of Warning
Queue
Entries
BYTE
Attribute
ID
Access
Rule
Name Data Type Description
0 Get Read
Warning
Queue Entry
Full/All Info
STRUCT of
Warning Text ARRAY of
BYTE
16 character string (no length
information, no terminating
null).
Warning
Code
WORD Fault Code.
Warning Time
Stamp (Time
Stamps not
available in all
products)
STRUCT
BYTE 1/100 Second (0 – 99).
BYTE Second (0 – 59).
BYTE Minute (0 – 59).
BYTE Hour (0 – 23).
BYTE
Day of Week (0 – 6).
➀
BYTE Date (1 – 31).
BYTE Month (1 – 12).
BYTE
Year (0 – 99
➁
).
➀ Sunday is a value of zero.
➁ Year is an offset from 1990.
