Installing the 1203-GK5 Module or 1336-GM5 Board 3-7
Installing a 1336-GM5 Board After selecting the cables that you need, read this section for
information and instructions on installing
Required Tools and Equipment
To install your 1336-GM5 board, you need the following tools and
equipment:
DeviceNet communications board (1336-GM5).
A kit that includes one grounding wrist strap, four Phillips
mounting screws, four stand-off nylon headers, one 5-pin
connector and one snap-in comm housing with mounting
instructions (supplied with board).
#1 Phillips screwdriver.
Appropriate cable for the DeviceNet connection. Refer to the
“Selecting Cables” on page 3-1
Electrostatic Discharge Precautions
Please read the following safety precaution carefully before installing
the 1336-GM5 communications board.
!
ATTENTION: The1336-GM5communicationsboard
contains ESD (Electrostatic Discharge) sensitive parts.
Static control precautions are required when installing,
testing, or servicing this board. Device malfunction may
occur if you do not follow ESD control procedures. If
you are not familiar with static control procedures, refer
to Rockwell Automation Publication 8000-4.5.2,
Guarding Against Electrostatic Damage, or other
applicable ESD protection handbook.
