Rockwell Automation Publication 2099-UM001D-EN-P - December 2012 101
Connect the Kinetix 7000 Drive System Chapter 4
External Shunt Module
Connections
External active shunt modules listed in the table on page 156 are compatible with
Kinetix 7000 drives. Follow these guidelines when wiring your external active
shunt module kit.
• Refer to Shunt Resistor on page 37
for important wiring
recommendations.
• Refer to Appendix
B for the Kinetix 7000 drive interconnect diagrams.
• Refer to the installation instructions provided with your shunt module.
SERCOS Fiber-optic Cable
Connections
This procedure assumes you have your Logix SERCOS interface module/PCI
card and Kinetix 7000 drive mounted and are ready to connect the fiber-optic
cables.
The SERCOS fiber-optic ring is connected using the SERCOS receive (Rx) and
transmit (Tx) connectors.
See page 65
to locate the SERCOS connectors on your Kinetix 7000 drive. See
the figure below to locate the connectors on your SERCOS interface module or
PCI card.
Plastic cable is available in lengths up to 32 m (105 ft). Glass cable is available in
lengths between 50 m (164 ft) and 200 m (656 ft).
When tightening screws to secure the wires to the DC bus terminals, see
Table 36
on page 90 for torque values.
When connecting Kinetix 7000 drives, use at least a 2090-SCEP1-0, 1 m (3
ft) or longer cable.
Larger drives may require longer cables.
