Rockwell Automation Publication 2099-UM001D-EN-P - December 2012 155
Specifications and Dimensions Appendix A
AC Line Filter Specifications
Line filters compatible with a Kinetix 7000 drive sourcing input power from an
AC power supply are listed below.
Line filters compatible with a Kinetix 7000 drive sourcing input power from a
regenerative DC bus with a 8720MC-RPS unit are listed below.
AC Line Reactors
380…480V, 50/60 Hz, three-phase, line reactors compatible with a Kinetix 7000
drive connected to a three-phase, AC input power source are listed below.
Table 62 - Compatible Kinetix 7000 Drives and AC Line Reactors
Kinetix 7000 Drive
Cat. No.
AC Line Filter
Cat. No.
2099-BM06-S
2090- XXLF-TC350
2099-BM07-S
2099-BM08-S 2090- XXLF-TC365
2099-BM09-S 2090- XXLF-TC3100
2099-BM10-S 2090- XXLF-TC3150
2099-BM11-S 2090- XXLF-TC3200
2099-BM12-S 2090- XXLF-TC3250
8720MC-RPS
Cat. No.
AC Line Filter
Manufacturer and Cat. No.
8720MC-RPS065BM-HV2 Schaffner: FN3100-80-35
Soshin Electric: HF3080C-TOA
8720MC-RPS190BM 8720MC-EF190-VB
Kinetix 7000 Drive
Cat. No.
3% Impedance Input Line Reactor
(1)
5% Impedance Input Line Reactor
(1)
IP00 (Open Style)
Cat. No.
IP11 (NEMA/UL Type 1)
Cat. No.
IP00 (Open Style)
Cat. No.
IP11 (NEMA/UL Type 1)
Cat. No.
2099-BM06-S 1321-3R45-B 1321-3RA45-B 1321-3R45-C 1321-3RA45-C
2099-BM07-S 1321-3R55-B 1321-3RA55-B 1321-3R55-C 1321-3RA55-C
2099-BM08-S 1321-3R80-B 1321-3RA80-B 1321-3R80-C 1321-3RA80-C
2099-BM09-S 1321-3R100-B 1321-3RA100-B 1321-3R100-C 1321-3RA100-C
2099-BM10-S 1321-3R130-B 1321-3RA130-B 1321-3R130-C 1321-3RA130-C
2099-BM11-S 1321-3R200-B 1321-3RA200-B 1321-3R200-C 1321-3RA200-C
2099-BM12-S 1321-3RB250-B 1321-3RAB250-B 1321-3RB250-C 1321-3RAB250-C
(1) Input line reactors were sized based on the NEC fundamental motor amps.
