Rockwell Automation Publication 2099-UM001D-EN-P - December 2012 39
Install the Kinetix 7000 Drive System Chapter 2
Mount the Kinetix 7000 Drive
Follow these steps to install your Kinetix 7000 drive.
1. Layout and mark the position for your drive in the enclosure.
Follow the Kinetix 7000 mounting information provided in Figure 16 on
page 40. Clearance requirements on page 27 must also be followed.
2. Attach the drive to the cabinet.
The recommended mounting bolts are listed in the table on page 40
.
Follow the recommended high-frequency (HF) bonding techniques as
shown in Bonding Modules
beginning on page 28.
Follow the lifting instructions found in the Kinetix 7000 High Power
Servo Drive Installation Instructions, publication 2099-IN003
.
3. Tighten all mounting fasteners.
SHOCK HAZARD: To avoid hazard of electrical shock, perform all mounting and
wiring of the drive prior to applying power. Once power is applied, connector
terminals may have voltage present even when not in use.
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful to
keep any metal debris from falling into it. Metal debris or other foreign matter
can become lodged in the circuitry, which can result in damage to components.
