Rockwell Automation Publication 2080-UM005B-EN-E - March 2015 73
Chapter
8
Using the Micro800 Remote LCD
This chapter provides a description of how you can use the Micro800 Remote
LCD with the Micro820 controller. It has the following sections.
Overview
The 2080-REMLCD module serves as a simple IP65 text display that allows the
configuration of such controller settings as IP address. It connects to the
Micro820 controller through the RS232 port. The Remote LCD module has a
dot matrix LCD with backlight and supports multilingual characters. The display
size is 3.5 inches with 192 x 64 pixel resolution.
It also has:
• Four arrow keys
• Six function keys
• ESC key
• OK key
• USB port for Connected Components Workbench connectivity
It supports:
• Small character set: 24 characters by 8 lines
• Large character set: 24 characters by 4 lines
• Extra large character set: displays 12 characters by 4 lines
The Remote LCD module supports English, French, Spanish, Italian and
Simplified Chinese languages for the Main Menu.
Topic Page
Overview 73
Text Display Mode 75
USB Mode 74
Backup and Restore 81
Hardware Features, Installation, and Specifications 81
