Rockwell Automation Publication 2080-UM005B-EN-E - March 2015 1
Chapter
1
Hardware Overview
This chapter provides an overview of the Micro820 hardware features. It has the
following topics:
Hardware Features
Micro820 controllers are 20-point economical brick style controllers with
embedded inputs and outputs. These controllers can accommodate up to two
plug-in modules and can connect to a remote LCD (2080-REMLCD) for
configuring. The Micro820 controller also has a microSD™ card slot for project
backup and restore, and datalog and recipe.
Topic Page
Hardware Features 1
Embedded microSD (Micro Secure Digital) Card Slot 3
Embedded RS232/RS485 Serial Port Combo 3
Embedded Ethernet Support 4
The Micro820 controller supports all Micro800 plug-in modules, except
for the 2080-MEMBAK-RTC.
For more information, see Micro800 Plug-in Modules User, publication
2080-UM004
.
