228 Power Supply Worksheet
Digital Output Modules 1746-OA8 0.185 -
1746-OA16 0.370 -
1746-OAP12 0.370 -
1746-OB6EI 0.046 -
1746-OB8 0.135 -
1746-OB16 0.280 -
1746-OB16E 0.135 -
1746-OB32
(1)
0.190 -
1746-OB32E 0.190 -
1746-OBP8 0.135 -
1746-OBP16 0.250 -
1746-OG16 0.180 -
1746-OV8 0.135 -
1746-OV16 0.270 -
1746-OV32
(1)
0.190 -
1746-OVP16 0.250 -
1746-OW4 0.045 0.045
1746-OW8 0.085 0.090
1746-OW16 0.170 0.180
1746-OX8 0.085 0.090
Digital Combination
Modules
1746-IO4 0.030 0.025
1746-IO8 0.060 0.045
1746-IO12 0.090 0.070
1746-IO12DC 0.080 0.060
Analog Input Modules 1746-NI4 0.025 0.085
1746-NI8 0.200 0.100
1746-NI16I 0.125 0.075
1746-NI16V 0.125 0.075
Analog Output Modules 1746-NO4I 0.055 0.195
1746-NO4V 0.055 0.145
1746-NO8I 0.120
0.250
(2)
0
(3)
1746-NO8V 0.120
0.160
(2)
0
(3)
Analog Combination
Modules
1746-FIO4I 0.055 0.150
1746-FIO4V 0.055 0.120
1746-NIO4I 0.055 0.145
1746-NIO4V 0.055 0.115
Hardware Component Cat. No. Maximum Current (A)
at 5V dc at 24V dc

Allen-Bradley SLC 500 Specifications

General

Programming Software	RSLogix 500
Communication Ports	RS-232, DH-485, DH+
Power Supply	120/240V AC or 24V DC
Programming Languages	Ladder Logic
Operating Temperature	0°C to 60°C (32°F to 140°F)
Relative Humidity	5% to 95% (non-condensing)
Memory	4K to 64K words (depending on the processor)
