Publication 1747-UM011G-EN-P - June 2008
Power Supply Worksheet 229
Specialty Modules 1746-BAS (-T) 0.150
0.040
(4)
1746-BLM 1.000 -
1746-BTM 0.110 0.085
1746-HSCE 0.320 -
1746-HSCE2 0.250 -
1746-HSRV 0.300 -
1746-HSTP1 0.300 -
1746-INT4 0.110 0.085
1746-NR4 0.050 0.050
1746-NR8 0.100 0.055
1746-NT4 0.060 0.040
1746-NT8 0.120 0.070
1746-QS 1.000 0.200
1746-QV 0.215 -
Communication Modules 1747-ACN15 0.900 -
1747-ACNR15 0.900 -
1747-ASB 0.375 -
1747-BSN 0.800 0
1747-DCM 0.360 -
1747-KE 0.150
0.040
(4)
1747-KFC15 0.640 0
1747-SCNR 0.900 -
1747-SDN 0.500 -
1747-SN 0.600 -
Peripheral Devices 1747-AIC 0 0.085
1747-DTAM 0
(5)
1747-PIC 0
(5)
1747-PSD NA NA
1747-UIC
(6)
NA NA
1761-NET-AIC
(7)
NA NA
(1)
Power supply loading for Series D and later modules.
(2)
J4 jumper set to RACK.
(3)
J4 jumper set to EXT.
(4)
When using the 1746-BAS or 1747-KE modules to supply power to an AIC draws its power through the module. Add 0.085 A
(the current loading for the 1761-AIC interface) to the 1746-BAS or 1747-KE module’s power supply loading value at 24V dc.
(5)
The 24V dc loading values of the 1747-PIC and 1747-DTAM interfaces are included in the 24V dc loading value of the processor.
(6)
USB power consumption is less than 100 mA.
(7)
Current for the 1761-NET-AIC must be supplied from an external 24V dc source. No current is consumed from the controller
when an external source is used.
Hardware Component Cat. No. Maximum Current (A)
at 5V dc at 24V dc
