APRILIA RSV 1000 R FACTORY Use And Maintenance Book

16
use and maintenance RSV 1000 R - RSV 1000 R FACTORY
10 11
6
8
9
7
1
5
4
2
3
ARRANGEMENT OF THE INSTRUMENTS/CONTROLS
KEY
1) Clutch lever
2) Ignition/steering lock switch ( -  - )
3) Instruments and indicators
4) Front brake lever
5) Throttle twistgrip
6) High beam flasher ()/LAP button (multifunction)
7) Light dimmer switch ( - )
8) Direction indicator switch ()
9) Horn button ()
10) Starter button ()
11) Engine kill switch ( - )

APRILIA RSV 1000 R FACTORY Specifications

General

Engine Type	V-Twin, 4-stroke
Displacement	998 cc
Transmission	6-speed
Max Power	143 hp (107 kW) @ 10, 000 rpm
Max Torque	107 Nm at 7500 rpm
Front Suspension	Öhlins upside-down fork
Rear Suspension	Öhlins monoshock
Front Brakes	Dual 320 mm discs
Rear Brakes	Single 220 mm disc
Dry Weight	185 kg
Fuel Capacity	18 liters
Frame	Aluminum twin spar
