FUNCTIONING4.
Operating logic4.1
0 - AUTOMATIC MODE
INPUT
AUTOMATION STATE START STOP CLOSING SAFETY
AUXILIARY
SAFETY
SAFETY
EDGE PHOTOCELL
closed opens
prevents
opening
- prevents opening prevents opening
open (pause) - locks
1
prevents closing (Ad)
-
prevents closing as
long as it is covered
closing re-opens locks
1
re-opens - locks
2
opening - locks
1
- reverses and locks locks
2
locked using STOP closes - - - -
1 - FOUR STEPS
Identical functioning to Automatic mode apart from the following differences:
open (pause)
START within 3 seconds of opening

locks the open automation; a further START

closes
2 - SUPER AUTOMATIC
Identical functioning to Automatic mode apart from the following differences: regardless of the movement phase, START
reverses the direction
open (pause)
START

closes ignoring the pause time
opening
START

closes again
3 - SEMI-AUTOMATIC WITH STOP
INPUT
AUTOMATION STATE START STOP CLOSING SAFETY
AUXILIARY
SAFETY
SAFETY EDGE PHOTOCELL
closed opens
prevents
opening
- prevents opening prevents opening
open closes locks
1
prevents closing (Ad)
-
prevents closing (Ad)
closing re-opens locks
1
re-opens - locks
2
opening locks
1
locks
1
- reverses and locks locks
2
locked using STOP closes - - - -
4 - STEP BY STEP
INPUT
AUTOMATION STATE START STOP CLOSING SAFETY
AUXILIARY
SAFETY
SAFETY EDGE PHOTOCELL
closed opens
prevents
opening
- prevents opening prevents opening
open closes locks
1
prevents closing (Ad)
-
prevents closing (Ad)
closing
locks
(START
opens again)
locks
1
re-opens - locks
2
opening locks
1
locks
1
- reverses and locks locks
2
locked using STOP closes - - - -
5 - MANNED
(commands held down
with key pushbutton)
An operator moves the gate using a key pushbutton.
Starting with the gates closed:
•
START

OPENS until the button is released or the movement is complete.
•
PEDESTRIAN START

CLOSES until the button is released or the movement is complete.
INPUT
AUTOMATION STATE
START
(OPENS)
PEDESTRIAN
START
(CLOSES)
STOP CLOSING SAFETY
AUXILIARY
SAFETY
SAFETY
EDGE PHOTOCELL
closed opens - locks -
prevents
opening
prevents
opening
open - closes locks
prevents
closing (Ad)
-
prevents
closing (Ad)
closing opens - locks locks
2
- locks
2
opening opens closes locks -
reverses and locks
locks
2
locked using STOP opens closes - - - -
6 - TIMER
- while START is enabled closing is inhibited -
- responses to inputs are the same as for AUTOMATIC MODE -
legend:
locks
1
: START causes immediate closing
locks
2
: movement is completed when the photocell is uncovered
