The Main Menu allows you to select an operation to perform. The Main Menu options include:
• View Drive Assignments: shows the status of the hard disk drives.
• LD View / LD Dene Menu:Dene Menu:: displays the existing RAID set information / creates a
RAID 0, RAID 1, RAID 5 or RAID 10 conguration.
• Delete LD Menu: deletes a selected RAID set and partition.
• Controller Conguration: shows the system resources conguration.
Press �1, �2, �3, or �4 to enter the option you need; press �ESC to exit the utility.
The RAID BIOS setup screens shown in this section are for reference only, and may not
exactly match the items on your screen.
To create a RAID volume using more than four hard disk drives, ensure that the SATA
connectors 5/6 are set to [RAID] mode.
Option ROM Utility (c) 2009 Advanced Micro Devices, Inc.
View Drive Assignments .......[ 1 ]
LD View / LD Dene Menu ......[ 2 ]
Delete LD Menu ...............[ 3 ]
Controller Conguration ......[ 4 ]
[ Main Menu ]
Press 1..4 to Select Option [ESC] Exit
[ Keys Available ]
4.5.4 AMD
®
Option ROM Utility
To enter the AMDAMD
®
Option ROM utility:Option ROM utility:
1. Boot up your computer.
2. During POST, press <Ctrl> + <F> to display the utility main menu.
