Frame Buffer Location [Above 4G]
Allows you to select the FB Location. Conguration options: [Below 4G] [Above 4G]
AMD HDMI Audio [Enabled]
Allows you to disable or enable the AMD 880 HD Audio.
Conguration options: [Disabled] [Enabled]
3.6.3 Onboard Devices Conguration
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
HDAudio Controller [Enabled]
Allows you to enable or disable the HD Audio controller.
Conguration options: [Disabled] [Enabled]
Front Panel Select [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or
high-denition audio depending on the audio standard that the front panel audio
module supports.
[AC 97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
[HD Audio] Sets the front panel audio connector (AAFP) mode to high denition audio.
Onboard LAN Controller [Enabled]
[Enabled] Enables the onboard LAN controller.
[Disabled] Disables the controller.
Onboard LAN Boot ROM [Disabled]
This item appears only when you set the previous item to [Enabled].
[Enabled] Enables the onboard Gigabit LAN Boot ROM.
[Disabled] Disables the LAN Boot ROM.
