ASUS M4A88TD-V EVO 3-29
Chapter 3
VT6330 1394/IDE Controller [Enabled]
[Enabled] Enables the onboard IEEE 1394a/IDE controller.
[Disabled] Disables the controller.
VT6330 IDE Boot ROM [Enabled]
[Enabled] Enables the VT6330 IDE Boot ROM.
[Disabled] Disables the VT6330 IDE Boot ROM.
3.6.4 PCIPnP
The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices.
Plug And Play O/S [No]
[Yes] When set to [Yes] and if you install a Plug and Play operating system, the
operating system congures the Plug and Play devices not required for boot.
[No] When set to [No], BIOS congures all the devices in the system.
E5889_M4A88TD-V EVO_Contents V2.29 29 5/26/10 4:05:17 PM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus M4A88TD-V EVO and is the answer not in the manual?

Asus M4A88TD-V EVO Specifications

General IconGeneral
SocketAM3
ChipsetAMD 880G
Memory Slots4
Memory TypeDDR3
Max Memory16GB
Memory StandardDDR3 2000(O.C.)/1333/1066
PCI Express x162
PCI Express x11
PCI Slots2
SATA 3Gb/s5
SATA 6Gb/s1
USB 2.0 Ports12
USB 3.0 Ports2
Form FactorATX
Onboard VideoATI Radeon HD 4250
Onboard LANRealtek 8111E Gigabit LAN
CrossFire SupportYes
Onboard AudioRealtek ALC892
RAID SupportRAID 0, 1, 10
