CPU/NB Offset Voltage [Auto]
This item appears only when you set the CPU & NB Voltage Mode item to [Offset]
and allows you to set the CPU/NB Offset voltage. The values range from 0.003125V to
0.500000V with a 0.003125V interval.
CPU Voltage [Auto]
This item appears only when you set the CPU & NB Voltage Mode item to [Manual] and
allows you to set a xed CPU voltage.
CPU/NB Voltage [Auto]
This item appears only when you set the CPU & NB Voltage Mode item to [Manual] and
allows you to set a xed CPU/NB voltage.
3.5.12 CPU VDDA Voltage [Auto]
Allows you to set the CPU VDDA voltage. The values range from 2.50V to 2.80V with a 0.10V
interval.
3.5.13 DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.20000V to 2.44500V with a
0.01500V interval.
3.5.14 HT Voltage [Auto]
Allows you to set the HyperTransport voltage. The values range from 1.20000V to 1.40000V
with a 0.01000V interval.
3.5.15 NB 1.2V Voltage [Auto]
Allows you to set the Northbridge 1.2V voltage. The values range from 1.20000V to 1.83000V
with a 0.01000V interval.
3.5.16 NB 1.1V Voltage [Auto]
Allows you to set the Northbridge 1.1V voltage. The values range from 1.10V to 1.40V with a
0.01V interval.
3.5.17 NB 1.8V Voltage [Auto]
Allows you to set the Northbridge 1.8V voltage. The values range from 1.80V to 1.90V with a
0.10V interval.
3.5.18 SB Voltage [Auto]
Allows you to set the Southbridge voltage. The values range from 1.10V to 1.40V with a
0.10V interval.
