** Audio 2, 4, 6, or 8-channel conguration
Port
Headset
2-channel
4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out
* LAN port LED indications
SPEED
LED
ACT/LINK
LED
LAN port
Activity Link LED Speed LED
Status Description Status Description
OFF No link OFF 10 Mbps connection
ORANGE Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
Dual display table
This table indicates whether the dual display you want to use is supported or not.
Dual display output Supported Not supported
DVI + D-Sub •
HDMI + D-Sub •
DVI + HDMI •
Playback of Blu-Ray Discs
For better playback quality, we suggest that you follow the system requirements in the
suggested list below.
Suggested list
CPU
AMD
®
Phenom II X4 955
DIMM
DDR3 1333
BIOS setup
Frame Buffer Size – 256MB or higher
Playback software
CyberLink
®
PowerDVD 9
File format
Best resolution
Windows XP Windows Vista Windows 7
Non-protected clips 1920 x 1080p 1920 x 1080p 1920 x 1080p
Blu-ray 1920 x 1080p 1920 x 1080p
1920 x 1080p
