10.6 Compressor data
For high ambient temperature versions operating above 46 °C (115 °F) a derating factor has
been applied. The derating factor lowers the maximum motor speed/input power (at constant
maximum pressure) to avoid overheating of the oil circuit and motor.
Data for 50 Hz, 8.5 bar (123.3 psi) Full-Feature compressors
Units GA 110 VSD+ GA 132 VSD+ GA 160 VSD+
Effective working pressure bar(g) 7 7 7
Effective working pressure psi(g) 101 101 101
Motor shaft speed rpm 3872 3556 3293
Maximum effective working pressure bar(g) 8.3 8.3 8.3
Maximum effective working pressure psi(g) 101 101 101
Air-cooled compressor version
Total electrical power input kW 136.2 162.2 197.1
Total electrical power input hp 182.6 217.4 164.2
Mean sound pressure level dB(A) 77 78 79
Oil capacity (approx.) l 106 110 110
Oil capacity (approx.) US gal 28 29.05 29.05
Oil capacity (approx.) Imp gal 23.32 24.2 24.2
Oil capacity (approx.) cu.ft 3.74 3.88 3.88
Water-cooled compressor version
Total electrical power input kW 133.5 159 191.6
Total electrical power input hp 179 213.1 256.8
Mean sound pressure level dB(A) 74 74 76
Oil capacity (approx.) l 94 98 98
Oil capacity (approx.) US gal 24.83 25.89 25.89
Oil capacity (approx.) Imp gal 20.68 21.56 21.56
Instruction book
9829 3178 63 121
Oil capacity (approx.) cu.ft 3.32 3.46 3.46
Cooling medium flow l/s 2.1 2.5 3.1
Cooling medium flow cfm 4.4 5.3 6.6
