Table 2.1: Descriptions for Figure 2.1
Number Description Number Description
1 Digital User 8 Power Cord
2 Telephone Network 9 Ports 1-32
3 Network 10 Local USB Connections
4 Modem 11 Power Control Device
5 Analog User 12 Servers 1-32
6 External Virtual Media 13 DSRIQ Modules PS/2, USB*, Sun and serial adaptors
are available.
7 DSR8035 Switch
* To open a virtual media session with a server, the server must first be connected to the switch using a
virtual media-capable DSRIQ module (USB2 or USB2L).
Chapter 2: Installation 7
Getting started
Before installing your DSR switch, refer to the following lists to ensure you have all items that
shipped with the DSR switch, as well as other items necessary for proper installation.
Supplied with the DSR switch
• Local country power cord
• Rack mounting brackets (depending on switch model)
• Rack Mounting Bracket Quick Installation Guide (depending on switch model)
• DSR Switch Quick Installation Guide
• Either of the following:
• Two ribbon cables with RJ-45 connectors at each end
One RJ-45 to DB-9 (male) adaptor for the modem connection
One RJ-45 to DB-9 (female) adaptor for the SETUP port
-or-
• One null modem cable
Additional items needed
• One DSRIQ module per target server or DSRIQ-SRL module per serial device
• One UTP patch cable per DSRIQ module (4-pair UTP, up to 10 meters)
• UTP patch cable(s) for network connectivity (4-pair UTP, up to 10 meters)
