22 DSR Switch Installer/User Guide
Figure 3.3: OSCAR Interface Commands Dialog Box
3. Select Scan Enable in the Commands dialog box.
4. Click X to close the Commands dialog box.
NOTE: Scanning will begin as soon as the Scan Enable button is selected.
To cancel Scan mode:
Select a target device if the OSCAR interface is open.
-or-
Move the mouse or press any key on the keyboard if the OSCAR interface is not open. Scanning
will stop at the currently selected target device.
-or-
If the OSCAR interface is not open, press Print Screen. The Main dialog box will appear.
a. Click Commands to open the Commands dialog box shown in Figure 3.3.
b. Clear Scan Enable.
Broadcasting to target devices
The local user can simultaneously control multiple target devices in a system to ensure that all
selected target devices receive identical input. You can choose to broadcast keystrokes and/or
mouse movements independently.
NOTE: You can broadcast to as many as eight target devices at a time (one target device per port).
To access the OSCAR interface Broadcast dialog box:
1. If the OSCAR interface is not open, press Print Screen to open the Main dialog box.
2. Click Setup - Broadcast to open the Broadcast dialog box shown in Figure 3.4.
